<strong>Water wells, mining exploration, seismic use, geothermal exploitation, geological investigation, well servicing, micropiling</strong>
Drillmec manufactures a wide range of waterwell rigs, multipurpose rigs and equipments for water well drilling, well development and geological surveys that have been successfully operating all over the world.
Drillmec rigs are either hydraulic or mechanical and are designed and manufactured according to a large selection of configurations and different solutions.
In order to cover most of drilling sector needs, Drillmec offers varied solutions and products besides the complete rigs, including rotary drilling equipment and consumables, rotary and hammer drilling equipment, drill pipes, drill collars and casing, drilling accessories, as long as training and long-term technical assistance on site, for maintenance and exploitation of drilling rigs.
Read more
<div class="first column">
Drillmec product line can also offer different auxìliary Equipment, such as:
<strong>Drilling Fluid Equipment – Mud System, Bulk Storage and Transfer, Mud Tanks, Mud Guns, Mud Monitoring, Seawater Cooling Units
</strong>
DRILLMEC designs and manufacture complete mud and bulk systems to be integrated into a complete DRILLMEC drilling package to offer a full integrated solution. DRILLMEC offering and portfolio includes standardized solutions as well as tailor made ones in accordance to specific needs and project requirements.
<strong>Skidding Systems
</strong>
DRILLMEC Skidding Systems are designed and tailor made according to specific drilling rig configuration, operational requirement and overall well slots to be covered.
DRILLMEC Skidding Systems portfolio include the conventional models:Gripper Jack type
<ul>
<li>Ratchet Jack</li>
<li>Lift & Roll</li>
</ul>
Combined with some unconventional skidding solutions for special applications :
<ul>
<li>Walking Systems</li>
<li>Rotating Hydraulic Driven Pivoting Wheels</li>
</ul>
Main characteristics taken into consideration where designing a skidding systems are the following main ones: capping beams size, distance between the wells, directions to cover, capping beams maximum allowable pressure and overall skidding capacity.
<strong>HPU
</strong>
Hydraulic power unit (HPU) is a critical part of a rig and all its operations.
DRILLMEC with its experience in Hydraulic Rigs and Hydraulic Equipmnet is capable to offer a wide range of hydraulic power units suitable to meet any customer application, international standard and capable to feed from individual equipment to complete drilling packages.
<strong>Air Unit</strong>
DRILLMEC air units are designed and tailor made in accordance to package requirements and pneumatic consumers on board of the drilling package.
<strong>Hydraulic Cathead</strong>
DRILLMEC Jack type hydraulic cathead system is composed by: hydraulic cylinder with wire line consisting of cylinder with backup post, anchor Adapter,
</div>
<div class="last column">
<p class="split">and wireline assembly.</p>
<strong>Top Drive and Travelling Block Retractable Dolly</strong>
DRILLMEC Dolly and block Retract Systems are designed both Top Drives and Travelling blocks in order to increase tripping speed and optimize drilling efficiency.
The Retractlable Dolly System is a custom designed parking system, specifically engineered to be integrated with derrick structures and drill floor arrangements on offshore rigs.
</div>
Read more
<span style="font-size: 8pt;">CBM Series is a special purpose line of drilling rigs and related equipment designed to meet specific requirements of shallow and deeper wells.
</span><span style="font-size: 8pt;"><strong>HH 55 - HH 75 - HH 102</strong> </span>
<span style="font-size: 8pt;">HH 55 - HH 75 - HH 102 are drilling rigs suitable for CBM Coal Bed Methane exlporation. The mast is telescopic and operates as a hydraulic hoist. The hydraulic top drive is permanently installed in its cradle and it doesn’t need to be removed during transportation. Therefore all the rig can be easily assembled without any crane.
</span>
<span style="font-size: 8pt;">An auxiliary jib crane on the mast side facilitates the rig up and allows to pick up tubular and various equipment from the ground to the drill floor. Drillmec completes ts package with power slips, power tong, torque wrench, casing make up device and bit break out tong. In the easiest configuration a pneumatic over hydraulic panel is on the mast side whereas a cyber chair can be supplied. Customizable control cabin with air conditioning system and self elevating system is provided upon request, as well as a powered rotary table.</span>
Read more
<div class="first column">
<span style="font-size: 10pt;">Everything about the HH Series is designed for speed, safety and efficiency. You can tell just by looking it is not a conventional rig. </span>
<span style="font-size: 8pt;"><span style="font-size: 10pt;">From it selferecting telescopic mast made from a single powerful hydraulic cylinder to the built-in integrated hydraulic top drive, HH rigs are designed to optimize your drilling plan from top to bottom. Automated systems, centralized control and few rig floor workers combine for a safer and more efficient drilling operation, better performance and reduced costs. The HH Series drilling processes are largely automated and centrally operated from the climate controlled driller’s cabin. Stuck pipe becomes less of an issue with features that allow automatic drilling even with preset WOBs and ROPs or top drive back reaming.</span>
</span>
</div>
<div class="last column"></div>
Read more
